OPENROAD 13 500 lb Electric Winches with Synthetic Rope
OPENROAD 13,500 lb Electric Winch — built for Aussie 4x4 recovery, river crossings and off-grid adventures.
Driven by a genuine 6.6 HP pure copper motor, this heavy-duty electric winch packs serious pulling strength — tough enough to haul full-size utes out of sticky bogs and back onto the track. Its full-steel 3-stage planetary gear system (218 : 1) delivers smooth, controlled power through every pull, while the 26 m × 9.5 mm synthetic rope keeps weight low and reliability high.
Backed by a 3-Year warranty, the OPENROAD 13,500 lb 4×4 Winch redefines power, protection and performance.
Built to perform wherever the track takes you.
From river crossings and muddy bog holes to dusty outback tracks and sudden downpours, the OPENROAD 13,500 lb Electric Winch is engineered to keep working when conditions turn tough. With an IP68 waterproof rating, sealed internals, and a full-steel 3-stage planetary gear system, it’s designed to resist water, dust, sand and corrosion — not just look tough, but stay reliable over time.
Powered by a genuine 6.6 HP pure copper motor, this winch delivers consistent pulling strength without overheating, even during repeated recoveries. Every component is built with durability in mind, giving you confidence that when you need it most, it will perform — no matter the environment.
Video
Features
Specification
Accessories
Ultimate Upgrade
Turn heads on and off the track with a rugged all-black winch design built for Aussie conditions. Not just a bold look — this upgrade delivers real pulling power and reliability when your adventure demands it most.
Maximum Power
Harness serious pulling strength with a genuine 6.6HP pure copper motor. Built tough to haul full-size utes out of sticky situations, this winch keeps its cool and delivers repeat performance trip after trip — no matter how remote the track.
Three-way control
Dual wireless remotes and a wired controller provide redundancy you can rely on — no single point of failure when conditions turn rough.
| Parameter | Specification |
|---|---|
| Rated Line Pull | 13,500 lbs (5,896 kg) |
| Motor | 6.6 hp / 5.0 kW, Series Wound |
| Gear Train | 3 Stage Planetary |
| Gear Reduction Ratio | 218:1 |
| Brake | Automatic Load-Holding |
| Control | 2 × Wireless Remote Control + 1 × Wire Remote Control |
| Battery | Recommended: 650 CCA |
| Battery Cables | 2 gauge, 1.83 m |
| Fairlead | 4-Way Roller Fairlead |
| Cable Type | Synthetic Rope |
| Cable Size (D × L) | 26 m × 9.5 mm (88 ft × 3/8") |
| Overall Dimensions (L × W × H) | 529 × 160 × 242 mm |
| Drum Size (D × L) | Diameter: 64 mm; Length: 224 mm |
| Weight | 29.5 kg |
| Waterproof Rating | IP68 |
| Line Speed (Max Line Pull) | 1.6 m/min |
| Amp Draw (Max Line Pull) | 320 A (@12 VDC) |
| Application | 4WD / Ute / SUV |
Not sure what you’ll need to set up your winch? No stress — we’ve sorted it for you.
This complete kit fits most bull bars and 4WD setups, saving you the hassle of running around for extra parts.
Whether you’re installing for the first time or upgrading your rig, everything you need is right here for a smooth, easy setup.
Included in the Kit:
• Panther Series 3S – 13,500 lb Electric Winch
• Wired Handheld Remote
• Dual Wireless Remotes
• Black Heavy-Duty Hook
• Bolt & Mounting Hardware Set
• User Manual
• OPENROAD Hat & Sticker
📥13 500 lb Electric Winches Manual
